A R C H I T E C T U R A L P R O F I L E S F 3 8 F38 RECESSED MODEL F38 F38-R-X-OP-S-DN DIMENSIONS 38mm x 75mm MOUNTING Recessed Mount STYLE Standard KELVIN 2700K*/3000K/3500K/4000K*/5000K* LENGTHS 1 - 8' / CR: Continuous Run/ PAT: Pattern LENS Opal LIGHT DIRECTION Up & Downlight LUMEN PACKAGES Standard: 7.5W, 813lm/ft. (3500K)/ High: 10W, 1162lm/ft. (3500K) VOLTAGE 120V-277V/347V* DIMMING 0-10V/TRIAC/Tuneable White*/Lutron*/Dim To Warm* FINISHES Black/White/Aluminum/Customization* (Require RAL#) APPROVAL Damp 1.5in [38mm] 2.95in [75mm] 1.97in [50mm] 1.04in [26.5mm] ORDERING GUIDE CONFIGURATOR PROFILE MOUNTING LENGTHS (FT.) (**See Lengths Chart below) LENS STYLE LIGHT DIRECTION F38 R RECESSED 1 2 3 OP OPAL S STANDARD DN DOWNLIGHT 4 5 6 7 8 CR CONTINUOUS RUN PAT PATTERN CCT LUMEN PACKAGE VOLTAGE DIMMING OPTIONS FINISHES 27 2700K ST STANDARD UN UNIVERSAL (120V - 277V) OS1 0-10V DIMMING 01 BLACK 30 3000K HI HIGH 347 347V* TRI TRIAC 02 WHITE 35 3500K TUN TUNABLE WHITE* AL ALUMINUM 40 4000K LUT LUTRON* CC CUSTOM COLOR SPECIFY RAL# 50 5000K DTW DIM TO WARM* **LENGTHS CHART MAXIMUM 8' PER CONTINUOUS PIECE 1' 11.5" 2' 22.5 3' 33.5" 4' 44.5" 5' 55.5" 6' 66.5" 7' 77.5" 8' 88.5" *Consult Factory ORDERING GUIDE EXAMPLE: Architectural Profiles F38 / Recessed / 3 ft. / Opal Lens / Standard Style / Downlight / 3000K / High Lumen / Universal Voltage / 0-10V Dimming / Black Finish CODE: F38-R-3-OP-S-DN-30-HI-UN-OS1-01 PATTERNS Common Miter Cut Patterns “T” “X” All corners are miter cut and customizable to any degree. Custom Patterns X = 23" min. Y = 23" min. X = 23" min. Y = 23" min. Z = 23" min. X = 23" min. Y = 23" min. Square L-Shape S X Rectangular R X Y U-Shape U X Z Y L Y X Contactsales@eurofase.com ELECTRICAL APPROVAL WARRANTY COMPLIANT TITLE 24 JA8 246 2022 BY
